Mitsubishi VFD A800 [FR-A840-00052-E2-60]
Industrial Automation / VFD / VFD
Mitsubishi, A800, FR-A840-00052-E2-60, Inverter AC; Pn: 0,75-2,2kW; 3x380-500V;In max: 5,2A;(1,5kW; 4A); IP20_ [FR-A840-00052-E2-60]
FA-Inverter: Inverter
Series | FR-A SERIES |
---|---|
Type | FR-A800-E INVERTER |
Minimum Rated Voltage (V) | 380 |
Min. Permissible Voltage (V) | 323 |
Maximum Rated Voltage (V) | 500 |
Max. Permissible Voltage (V) | 550 |
Current Type | AC |
Phases | 3 |
Rated Output Current SLD (A) | 5,2 |
Rated Output Current LD (A) | 4,8 |
Rated Output Current ND (A) | 4 |
Rated Output Current HD (A) | 2,5 |
Rated Motor Capacity SLD (kW) | 2,2 |
Rated Motor Capacity LD (kW) | 2,2 |
Rated Motor Capacity ND (kW) | 1,5 |
Rated Motor Capacity HD (kW) | 0,75 |
Control Method | PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL, REAL SENSORLESS VECTOR CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, V/F CONTROL, VECTOR CONTROL (WITH FR-A8AP) |
Motor Type | INDUCTION MOTOR, PM MOTOR |
Brake Chopper ED (%) | 100 |
Integrated EMC Filter | YES |
Safe Torque Off (STO) | YES |
Regenerative (4Q) | NO |
Integrated DC Choke | NO |
Display | FR-DU08 |
Display Type | 5 DIGITS LED (12 SEGMENT) |
PLC Function | YES |
Program Memory | 6K |
Program Memory Unit | STEPS |
Integrated Digital Inputs | 12 |
Digital Outputs (Transistor) | 5 |
Digital Outputs (Relay) | 2 |
Integrated Analogue Inputs | 3 |
Integrated Analogue Outputs | 2 |
IO Type of Terminal Block | SPRING CLAMP |
Expandable | YES |
RS-485 | OPTIONAL |
USB | 1+1 MINI |
Ethernet Port | 1 |
Built-In Network | CC-LINK IE FIELD NETWORK BASIC, CC-LINK IE FIELD NETWORK, MODBUS/TCP |
Leakage Current (mA) | 35(DELTA) / 2(STAR) |
Power Loss SLD (W) | 85 |
Power Loss LD (W) | 80 |
Power Loss ND (W) | 70 |
Power Loss HD (W) | 50 |
Frequency Range (Hz) | 0,2–590 |
Standby Power Consumption (W) | 19 |
Protection Class | IP20 |
Product Dimensions & Weight
Width (mm) | 150 |
---|---|
Height (mm) | 260 |
Depth (mm) | 140 |
Weight (kg) | 2,8 |
