Mitsubishi VFD A800 [FR-A840-00052-E2-60]

Mitsubishi VFD A800 [FR-A840-00052-E2-60]

https://www.hsedubai.com/web/image/product.template/20562/image_1920?unique=29e3b48

Industrial Automation / VFD / VFD

2,051.00 AED 2051.0 AED 2,051.00 AED

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions
    30-day money-back guarantee
    Shipping: usually 2-3 Business Days, once order is placed, actual lead time will be confirmed.

    Share

    Mitsubishi, A800, FR-A840-00052-E2-60, Inverter AC; Pn: 0,75-2,2kW; 3x380-500V;In max: 5,2A;(1,5kW; 4A); IP20_ [FR-A840-00052-E2-60]

    FA-Inverter: Inverter

    SeriesFR-A SERIES
    TypeFR-A800-E INVERTER
    Minimum Rated Voltage (V)380
    Min. Permissible Voltage (V)323
    Maximum Rated Voltage (V)500
    Max. Permissible Voltage (V)550
    Current TypeAC
    Phases3
    Rated Output Current SLD (A)5,2
    Rated Output Current LD (A)4,8
    Rated Output Current ND (A)4
    Rated Output Current HD (A)2,5
    Rated Motor Capacity SLD (kW)2,2
    Rated Motor Capacity LD (kW)2,2
    Rated Motor Capacity ND (kW)1,5
    Rated Motor Capacity HD (kW)0,75
    Control MethodPM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL, REAL SENSORLESS VECTOR CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, V/F CONTROL, VECTOR CONTROL (WITH FR-A8AP)
    Motor TypeINDUCTION MOTOR, PM MOTOR
    Brake Chopper ED (%)100
    Integrated EMC FilterYES
    Safe Torque Off (STO)YES
    Regenerative (4Q)NO
    Integrated DC ChokeNO
    DisplayFR-DU08
    Display Type5 DIGITS LED (12 SEGMENT)
    PLC FunctionYES
    Program Memory6K
    Program Memory UnitSTEPS
    Integrated Digital Inputs12
    Digital Outputs (Transistor)5
    Digital Outputs (Relay)2
    Integrated Analogue Inputs3
    Integrated Analogue Outputs2
    IO Type of Terminal BlockSPRING CLAMP
    ExpandableYES
    RS-485OPTIONAL
    USB1+1 MINI
    Ethernet Port1
    Built-In NetworkCC-LINK IE FIELD NETWORK BASIC, CC-LINK IE FIELD NETWORK, MODBUS/TCP
    Leakage Current (mA)35(DELTA) / 2(STAR)
    Power Loss SLD (W)85
    Power Loss LD (W)80
    Power Loss ND (W)70
    Power Loss HD (W)50
    Frequency Range (Hz)0,2–590
    Standby Power Consumption (W)19
    Protection ClassIP20

    Product Dimensions & Weight

    Width (mm)150
    Height (mm)260
    Depth (mm)140
    Weight (kg)2,8
