Mitsubishi VFD A800 [FR-A840-00052-E2-60]

Mitsubishi VFD A800 [FR-A840-00052-E2-60]

https://www.hsedubai.com/web/image/product.template/20562/image_1920?unique=ebe00a5

Industrial Automation / VFD / VFD

2,051.00 AED 2051.0 AED 2,051.00 AED

2,051.00 AED

Not Available For Sale

This combination does not exist.

Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: usually 2-3 Business Days, once order is placed, actual lead time will be confirmed.

Attachme​nts

Mitsubishi, A800, FR-A840-00052-E2-60, Inverter AC; Pn: 0,75-2,2kW; 3x380-500V;In max: 5,2A;(1,5kW; 4A); IP20_ [FR-A840-00052-E2-60]

FA-Inverter: Inverter

SeriesFR-A SERIES
TypeFR-A800-E INVERTER
Minimum Rated Voltage (V)380
Min. Permissible Voltage (V)323
Maximum Rated Voltage (V)500
Max. Permissible Voltage (V)550
Current TypeAC
Phases3
Rated Output Current SLD (A)5,2
Rated Output Current LD (A)4,8
Rated Output Current ND (A)4
Rated Output Current HD (A)2,5
Rated Motor Capacity SLD (kW)2,2
Rated Motor Capacity LD (kW)2,2
Rated Motor Capacity ND (kW)1,5
Rated Motor Capacity HD (kW)0,75
Control MethodPM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL, REAL SENSORLESS VECTOR CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, V/F CONTROL, VECTOR CONTROL (WITH FR-A8AP)
Motor TypeINDUCTION MOTOR, PM MOTOR
Brake Chopper ED (%)100
Integrated EMC FilterYES
Safe Torque Off (STO)YES
Regenerative (4Q)NO
Integrated DC ChokeNO
DisplayFR-DU08
Display Type5 DIGITS LED (12 SEGMENT)
PLC FunctionYES
Program Memory6K
Program Memory UnitSTEPS
Integrated Digital Inputs12
Digital Outputs (Transistor)5
Digital Outputs (Relay)2
Integrated Analogue Inputs3
Integrated Analogue Outputs2
IO Type of Terminal BlockSPRING CLAMP
ExpandableYES
RS-485OPTIONAL
USB1+1 MINI
Ethernet Port1
Built-In NetworkCC-LINK IE FIELD NETWORK BASIC, CC-LINK IE FIELD NETWORK, MODBUS/TCP
Leakage Current (mA)35(DELTA) / 2(STAR)
Power Loss SLD (W)85
Power Loss LD (W)80
Power Loss ND (W)70
Power Loss HD (W)50
Frequency Range (Hz)0,2–590
Standby Power Consumption (W)19
Protection ClassIP20

Product Dimensions & Weight

Width (mm)150
Height (mm)260
Depth (mm)140
Weight (kg)2,8
