Mitsubishi PLC Melsec FX3U_ Mitsubishi Melsec FX3U FX3U-48MT/ESS_ [FX3U-48MT/ESS]
Industrial Automation / PLC / Compact PLC
Mitsubishi, Melsec FX3U, FX3U-48MT/ESS, PLC, FX3U Base Unit AC 100-240 V; 24 inputs DC 24 V; 24 transistor outputs_ [FX3U-48MT/ESS]
FA-COM PLC: Main Unit
Type | FX3U |
---|---|
Power Supply (V) | 100-240 |
Current Type | AC |
Program Memory | 64K STEPS |
Program Memory Unit | RAM |
Integrated Digital Inputs | 24 |
Integrated Digital Outputs | 24 |
Output Type | TRANSISTOR |
Output Logic | SOURCE |
Local I/O Points | 256 |
Local + Remote I/O Points | 384 |
Expandable | YES |
Cycle Time LD (ns) | 65 |
Cycle Time MOV (ns) | 642 |
USB | OPTION |
RS-422 | 1 |
Power Consumption (W) | 40 |
Buffer Battery | YES |
Protection Class | IP10 |
Min. Ambient Temperature (°C) | 0 |
Max. Ambient Temperature (°C) | 55 |
Series | MELSEC-F SERIES |
Product Dimensions & Weight
Width (mm) | 182 |
---|---|
Height (mm) | 90 |
Depth (mm) | 86 |
Weight (kg) | 0,85 |
